8086 1-byte opcodes: all have to go

The 8086 has 95 1-byte opcodes. I'll keep only 8:

• CS:, DS:, ES:, SS:
• NOP
• RET, RETF
• INT 3

NOP and INT 3 must be 1-byte. The other six are frequently used. Everything else must go (i.e. become 2-byte opcode).

It is kind of a waste to use 4 slots on segment prefixes when they are going away on 32-bit architecture... (or do they? They will truly go away in 64-bit architecture.)

Some multi-byte instructions that favour registers must also go:

• MOV reg, immed
• ADD/SUB/... ax, immed
• TEST ax, immed
• MOV ax, [disp]
• MOV [disp], ax

Specialized instructions

A few comes to mind: MUL/IMUL, DIV/IDIV, SHL/ROL family, IN/OUT, CBW/CWD, JCXZ, LOOP, XLAT.

MUL/IMUL puts the result in DX:AX. It "wastes" DX even if we are not interested in it. Can generalize it partially.

DIV/IDIV divides DX:AX and puts the reminder in DX. It is common for starting DX to be zero (i.e. divide 16-bit by 16-bit). Can generalize it partially.

SHL/ROL uses CL. Shifts are usually constant. RCL/RCR only makes sense with 1.

IN/OUT uses AX and DX. Ports are usually accessed in a group. If we allow IN reg, [reg+disp], we just need to assign the base port address once.

CBW uses AX. CWD uses DX:AX. Can generalize (partially) to use other registers.

JCXZ and LOOP use CX. Can generalize to allow other registers.

XLAT uses BX and AL. Can generalize to use other registers.

Immediate operand

It turns out that it is common to operate on small numbers.

We can allow OP reg, i5s in 2-bytes and it would be much more useful. This gives registers an advantage over memory operands.

With this, there is no need for INC/DEC instructions.

Stack

PUSH i8s and PUSH i16 are also useful.

Instead of 1-byte PUSH reg, we can have 2-byte PUSH reg-mask. Normally we want to save a group of registers.

SP is no longer a GPR. We have explicit MOV and ADD for it. Other operations do not make sense for it.

Jumps

JS/JNS (Jump if signed) and JP/JNP (Jump if Parity) are useless. Remove them totally.

Allow all conditional jumps to have 16-bit offsets.

Near and far calls

I'll love to have a single set of RET that can handle both near and far returns, but unfortunately I am not able to think of a way.

We can differentiate near and far CALLs if we restrict call targets to start at even addresses. In that case, an even target is a near call and an odd target is a far call.

Strings

Remove REP and REPNE. Strings must be manually looped. These two are "signature" x86 instructions.

LODS, STOS, SCAS can use registers other than AX.

I'm thinking whether we need MOVS. It can be implemented as:

  JCXZ skip
@@:
  LODSW
  STOSW
  LOOP @b
skip:

REP MOVSW is tempting because it looks like it is the fastest way to move memory. It was, but there are faster ways now.

In fact, do we even need LODS, STOS and LOOP?

  JCXZ skip
@@:
  MOV ax, [si]
  ADD si, 2
  MOV [di], ax
  ADD di, 2
  DEC cx
  JNZ @b
skip:

(Assuming forward direction.)

ESC

Add an additional byte after ESC to increase co-processor opcode space. The 8087 is stack-based, most operations work on the ToS (top-of-stack), making it hard to pipeline in the future (starting with Pentium). Make it register-based.

Instruction formats

Make the formats oriented for "fast" decoding:

(This covers 99% of the instructions.)

RISC-ify?

Characteristics of RISC:

• Register-based operations, with explicit operands (e.g. d = s1 op s2)
• Memory access limited to MOV, mostly
• Large register bank
• Fixed length instruction

8086, like most (all?) CISC, can operate on memory directly, i.e.

ADD ax, mem
ADD mem, ax

Reading from memory and operating on it is fine, but operating on memory directly? It is fine for a single operation, but a series of operations will have unnecessary read/writes. For example:

ADD mem, 3
AND mem, ~0x03
SHL mem, 1

(3 reads and 3 writes)

vs

MOV ax, mem
ADD ax, 3
AND ax, ~0x03
SHL ax, 1
MOV mem, ax

(1 read and 1 write)

Reimaging the 8086. What if?

The 8086 had a tremendous impact in the Personal Computer space. But for over a decade, it tortured programmers with its limitations. They went away only when people started using 80386 in 32-bit mode. What if it were better designed?

Address space

The first issue is its "small" 20-bit address space. We need to understand the historical context. The 8086 was released in 1978, meaning it was planned and designed several years earlier. Those were the days of 8-bit microprocessors and 16-bit address space (64 kB RAM). 1 MB was 16 times of that. It was more memory than anyone could imagine using. (Memory was expensive in those days.)

8086 achieved 20-bit addressing by left-shifting segment registers by 4 and and adding 16-bit address.

What if it had left-shift by 8 instead?

It would have 24-bit address space for a total of 16 MB!

I doubt anyone made use of the fact that segments are 16-bytes apart to layout their data structures. (You can conceivably index into an array of 16-byte structure with just the segment register.)

16 MB would go a long way in simplifying memory management. Instead, programmers had to deal with upper memory, expanded memory, extended memory and using "overlay" techniques. 16 MB was a lot of memory. It was not until mid-90s that 16 MB memory became common. (Windows 95 had to run with just 4 MB memory because it was a common low-end configuration.)

The biggest problem with 24-bit address space is that we need 4 more pins. 8086 comes in a 40-pin DIP that is already heavily multiplexed. A16 - A19 are already multiplexed with status pins. Can we find another 4 pins to multiplex A20 - A23?

The registers

The 8086 has 8 registers. The 16-bit registers are: AX, BX, CX, DX, SI, DI, BP, SP. They have predefined purposes, so it is hard for compilers (of that era) to optimize their usage.

The problem is slightly worse than that.

BP and SP are not usable in general. SP is the stack pointer. It must point to the stack. BP is the frame pointer and generally points to the stack frame in a HLL. If we pass parameters on the stack, we need BP because [SP+disp] does not exist, only [BP+disp].

Rather than BP and SP, let's introduce EX and FX instead. Now we have 8 GPRs (General Purpose Registers).

8 is not a lot, but it is generally enough. Compilers of that era like big register bank because they are not good at dynamic register allocation.

While we are at it, let's fix 8-bit registers too. The 8-bit registers are: AL, AH, BL, BH, CL, CH, DL, DH. It is a 'clever' way to access both halves of a 16-bit register.

But is it really needed?

This introduced a problem six generations down the road — on Pentium Pro — that does register renaming.

Let's define 8-bit registers this way: AL, BL, CL, DL, EL, FL. Yes, just 6 of them.

Addressing mode

The current addressing mode:

We only have 3 general indirect registers, [bx], [si] and [di] since [bp+disp] points to the stack. (Though in the "small" and "medium" memory model, data and stack shares the same 64 kB segment.)

Do we really need [base+index]? While this is nice to have, it turns out that [reg] is generally enough.

Behold the new table:

There are three notable changes.

First, we now have 5 general indirect registers: [bx], [ex], [fx], [si] and [di].

Second, there is no need for [bp+disp] since we can just use [sp+disp] directly. SP is not a GPR, but we can still use it to access the stack. (We need to define explicit instructions to manipulate it.)

Third, [ip+disp] allows us to access data in code segment relative to the current instruction. This is useful for PIC (Position Independent Code) that would become vogue one and a half decade later.

Instruction set

The 8086 instruction set has many 1-byte opcodes. Many of them are infrequently used. In hindsight, it would be better to define them as 2-byte opcodes and free up space in the first byte.

The 8086 has only 23 unused slots in the first byte.

The "packing" of instructions also made the instruction set less orthogonal and increased decoding complexity.

There are some instructions that are one-byte shorter for registers:

• PUSH reg
• POP reg
• INC reg
• DEC reg
• MOV reg, immed

These use up 48 slots in the first-byte opcode map.

AX gets preferential treatment:

• ADD/SUB/... ax, immed
• TEST ax, immed
• MOV ax, [disp]
• MOV [disp], ax
• XCHG ax, reg

These use up 29 slots. (XCHG ax, ax is NOP and hence not counted.)

Are these worth saving one byte? Perhaps, but I'll rather have more general instructions. For example, instead of INC reg, why not have a 2-byte ADD reg, i5s? It'll allow +/-15, which is more useful.

In those days, there was no expectation to keep the same instruction set over generations. Every new microprocessor had its own instruction set. The 8086 instruction set was optimized for its implementation. Unfortunately, it made things difficult for its successors, especially Pentium onwards, when the CPU went superscalar.
